ESL-20 200-320W Projector
TECHNICIAL SPECIFICATIONS
| Body Material | Injection Aluminum |
|---|---|
| Lens Angle | 20~120° |
| Power Consumption | 200-320W |
| Source of Light | Armageddon |
| Operating Voltage | 100 ~240 VAC 50/60Hz |
| Color Temperature | - |
| CRI | >70 |
| IP Class | IP66 |
| Product Description | Operating Voltage | Power Consumption (W) | Luminous Flux (lm) | Datasheet | LDT | Technical Drawing |
|---|---|---|---|---|---|---|
| 20° Lens | ||||||
| ESL-20~200W Projector | 100 - 240 VAC 50/60Hz | 200W | 26400 | |||
| ESL-20~240W Projector | 100 - 240 VAC 50/60Hz | 240W | 31200 | |||
| ESL-20~280W Projector | 100 - 240 VAC 50/60Hz | 280W | 35300 | |||
| ESL-20~320W Projector | 100 - 240 VAC 50/60Hz | 320W | 39350 | |||
| 45° Lens | ||||||
| ESL-20~200W Projector | 100 - 240 VAC 50/60Hz | 200W | 30000 | |||
| ESL-20~240W Projector | 100 - 240 VAC 50/60Hz | 240W | 34800 | |||
| ESL-20~280W Projector | 100 - 240 VAC 50/60Hz | 280W | 39750 | |||
| ESL-20~320W Projector | 100 - 240 VAC 50/60Hz | 320W | 44500 | |||
| 60° Lens | ||||||
| ESL-20~200W Projector | 100 - 240 VAC 50/60Hz | 200W | 30200 | |||
| ESL-20~240W Projector | 100 - 240 VAC 50/60Hz | 240W | 34650 | |||
| ESL-20~280W Projector | 100 - 240 VAC 50/60Hz | 280W | 39500 | |||
| ESL-20~320W Projector | 100 - 240 VAC 50/60Hz | 320W | 43500 | |||
| 90° Lens | ||||||
| ESL-20~200W Projector | 100 - 240 VAC 50/60Hz | 200W | 30800 | |||
| ESL-20~240W Projector | 100 - 240 VAC 50/60Hz | 240W | 35500 | |||
| ESL-20~280W Projector | 100 - 240 VAC 50/60Hz | 280W | 40600 | |||
| ESL-20~320W Projector | 100 - 240 VAC 50/60Hz | 320W | 44800 | |||
| 120° Lens | ||||||
| ESL-20~200W Projector | 100 - 240 VAC 50/60Hz | 200W | 30800 | |||
| ESL-20~240W Projector | 100 - 240 VAC 50/60Hz | 240W | 35500 | |||
| ESL-20~280W Projector | 100 - 240 VAC 50/60Hz | 280W | 40300 | |||
| ESL-20~320W Projector | 100 - 240 VAC 50/60Hz | 320W | 44500 |
